Available to control 2048 parameters（Available to control max 65536 parameters when connecting to TEKMAND system）
4 DMX inputs/outputs
MIDI input/output
LTC/ Smpte input
6 executive faders
2 A/B faders
1 dimmer wheel
4 encoders
Available to adjust brightness of key backlight
Available to connect with TEKMAND on PC system via USB
Available to control 2048 parameters（Available to control max 65536 parameters when connecting to TEKMAND system）
4 DMX inputs/outputs
MIDI input/output
LTC/ Smpte input
6 executive faders
2 A/B faders
1 dimmer wheel
4 encoders
Available to adjust brightness of key backlight
Available to connect with TEKMAND on PC system via USB
Power Supply: 100-240V~, 0.12A, 50/60 Hz
Max Power: 6.7W
IP Rate: IP 20
Working Temperature：-10～40ºC
Power Supply: 100-240V~, 0.12A, 50/60 Hz
Max Power: 6.7W
IP Rate: IP 20
Working Temperature：-10～40ºC
Product Dimension：530 x 327 x 72mm
Package Dimension：570 x 380 x 100mm
Package：1 pc / carton
Net Weight：3.2 kg
Gross Weight：4.7 kg
Product Dimension：530 x 327 x 72mm
Package Dimension：570 x 380 x 100mm
Package：1 pc / carton
Net Weight：3.2 kg
Gross Weight：4.7 kg
